OLENERGIES GAMME DÉDIÉE
FRANCE BATTERY
Gamme OlenBox
| NOM | Fiche technique | Tension | Capacité | Énergie | Courant de charge | Courant Max de Décharge | Courant pic de décharge instantané | Dimensions (L*W*H) | Tension de charge | Poids | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| V | Ah | Wh | A | A | A | mm | V | kg | ||||
| 1 |  | OlenBox 1 version 12V |  | 12.8 | 7.5 | 96 | 7.5 | 15 | 50±10(A) Duration: 10±5(mS) | 51*65*96mm | 14.6 | 1.23 |
| 2 |  | OlenBox 1+ version 12V | | 12.8 | 12 | 154 | 12 | 30 | 60±10(A) Duration: 10±5(mS) | 151*98*95mm | 14.6 | 1.66 |
| 3 |  | OlenBox 2 version 12V | | 12.8 | 25.6 | 328 | 10 | 30 | 60±10(A) Duration: 10±5(mS) | 181*77*167mm | 14.6 | 3.5 |
| 4 |  | OlenBox 4+ version 12V | | 12.8 | 42 | 538 | 38 | 70 | 270±30(A) Duration: 20±5(mS) | 195*130*162mm | 14.6 | 5.9 |
| 5 |  | OlenBox 4 version 24V | | 25.6 | 19.2 | 492 | 19 | 50 | 200±30(A) Duration: 10±5(mS) | 195*130*162mm | 29.2 | 5.9 |
| 6 |  | OlenBox 5 version 12V | | 12.8 | 51.2 | 655 | 50 | 60 | 650±30(A) Duration: 10±5(mS) | 224*135*212mm | 14.6 | 7.53 |
| 7 |  | OlenBox 5C version 12V | | 12.8 | 51.2 | 655 | 15 | 20 | 25(A) Duration: 30(S) | 195*130*185mm | 14.6 | 6.3 |
| 8 |  | OlenBox 7 version 12V | | 12.8 | 77 | 983 | 50 | 120 | 650±30(A) Duration: 10±5(mS) | 257x165x212mm | 14.6 | 9.35 |
| 9 |  | OlenBox 10+ version 12V | | 12.8 | 103 | 1311 | 50 | 120 | 650±30(A) Duration: 10±5(mS) | 257*165*212mm | 14.6 | 13.1 |
| 10 |  | OlenBox 10+ version 24V | | 25.6 | 51.2 | 1311 | 50 | 60 | 200±30(A) Duration: 10±5(mS) | 257*165*212mm | 29.2 | 13.1 |
| 11 |  | OlenBox 10+ version 48V | | 51.2 | 25.6 | 1311 | 20 | 50 | 200±30(A) Duration: 10±5(mS) | 257*165*212mm | 58.4 | 13.1 |
| 12 |  | OlenBox 15 version 12V | | 12.8 | 153.6 | 1966 | 50 | 120 | 650±30(A) Duration: 10±5(mS) | 485*170*240mm | 14.6 | 21.3 |
| 13 |  | OlenBox 18 version12V | | 12.8 | 180 | 2580 | 90 | 200 | 650±30(A) Duration: 10±5(mS) | 485*170*241mm | 14.6 | 24.3 |
| 14 | | OlenBox 20 version12V | | 12.8 | 201.6 | 2580 | 60 | 140 | 650±30(A) Duration: 10±5(mS) | 485*170*241mm | 14.6 | 26.8 |
| 15 | | OlenBox 20 version24V | | 25.6 | 100 | 2540 | 50 | 60 | 200±30(A) Duration: 10±5(mS) | 485*170*241mm | 29.2 | 26.8 |
| 16 | | OlenBox 20 version48V | | 51.2 | 51.2 | 2650 | 25 | 50 | 150 | 485*170*241mm | 58.1 | 27 |
| 17 | | OlenBox 20 version96V | | 96 | 26 | 2500 | 12 | 25 | 50 | 485*170*241mm | 108.2 | 26.8 |
| NOM | Fiche technique | Tension | Capacité | Énergie | Courant de charge | Courant Max de Décharge | Courant pic de décharge instantané | Dimensions (L*W*H) | Tension de charge | Poids | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| V | Ah | Wh | A | A | A | mm | V | kg | ||||
| 1 | | OlenBox 1 version 12V | | 12.8 | 7.5 | 96 | 7.5 | 15 | 50±10(A) Duration: 10±5(mS) | 51*65*96mm | 14.6 | 1.23 |
| 2 | | OlenBox 1+ version 12V | | 12.8 | 12 | 154 | 12 | 30 | 60±10(A) Duration: 10±5(mS) | 151*98*95mm | 14.6 | 1.66 |
| 3 | | OlenBox 2 version 12V | | 12.8 | 25.6 | 328 | 10 | 30 | 60±10(A) Duration: 10±5(mS) | 181*77*167mm | 14.6 | 3.5 |
| 4 | | OlenBox 4+ version 12V | | 12.8 | 42 | 538 | 38 | 70 | 270±30(A) Duration: 20±5(mS) | 195*130*162mm | 14.6 | 5.9 |
| 5 | | OlenBox 4 version 24V | | 25.6 | 19.2 | 492 | 19 | 50 | 200±30(A) Duration: 10±5(mS) | 195*130*162mm | 29.2 | 5.9 |
| 6 | | OlenBox 5 version 12V | | 12.8 | 51.2 | 655 | 50 | 60 | 650±30(A) Duration: 10±5(mS) | 224*135*212mm | 14.6 | 7.53 |
| 7 | | OlenBox 5C version 12V | | 12.8 | 51.2 | 655 | 15 | 20 | 25(A) Duration: 30(S) | 195*130*185mm | 14.6 | 6.3 |
| 8 | | OlenBox 7 version 12V | | 12.8 | 77 | 983 | 50 | 120 | 650±30(A) Duration: 10±5(mS) | 257x165x212mm | 14.6 | 9.35 |
| 9 | | OlenBox 10+ version 12V | | 12.8 | 103 | 1311 | 50 | 120 | 650±30(A) Duration: 10±5(mS) | 257*165*212mm | 14.6 | 13.1 |
| 10 | | OlenBox 10+ version 24V | | 25.6 | 51.2 | 1311 | 50 | 60 | 200±30(A) Duration: 10±5(mS) | 257*165*212mm | 29.2 | 13.1 |
| 11 | | OlenBox 10+ version 48V | | 51.2 | 25.6 | 1311 | 20 | 50 | 200±30(A) Duration: 10±5(mS) | 257*165*212mm | 58.4 | 13.1 |
| 12 | | OlenBox 15 version 12V | | 12.8 | 153.6 | 1966 | 50 | 120 | 650±30(A) Duration: 10±5(mS) | 485*170*240mm | 14.6 | 21.3 |
| 13 | | OlenBox 18 version12V | | 12.8 | 180 | 2580 | 90 | 200 | 650±30(A) Duration: 10±5(mS) | 485*170*241mm | 14.6 | 24.3 |
| 14 | | OlenBox 20 version12V | | 12.8 | 201.6 | 2580 | 60 | 140 | 650±30(A) Duration: 10±5(mS) | 485*170*241mm | 14.6 | 26.8 |
| 15 | | OlenBox 20 version24V | | 25.6 | 100 | 2540 | 50 | 60 | 200±30(A) Duration: 10±5(mS) | 485*170*241mm | 29.2 | 26.8 |
| 16 | | OlenBox 20 version48V | | 51.2 | 51.2 | 2650 | 25 | 50 | 150 | 485*170*241mm | 58.1 | 27 |
| 17 | | OlenBox 20 version96V | | 96 | 26 | 2500 | 12 | 25 | 50 | 485*170*241mm | 108.2 | 26.8 |
Gamme de Chargeurs
| Ref | Fiche technique | Tension | Ampérage | Puissance | Redémarrage auto | Dimensions (L*W*H) | Poids | ||
|---|---|---|---|---|---|---|---|---|---|
| V | A | W | ✓ / X | mm | kg | ||||
| XS | CH-XS12V5A-R |  | | 12 | 5 | 96 | ✓ | 135*90*50 | 0.8 |
| XS | CH-XS12V8A-R |  | | 12 | 8 | 154 | ✓ | 130*86*46 | 0.8 |
| XS | CH-XS12V15A-R |  | | 12 | 15 | 328 | ✓ | 135*90*50 | 1 |
| XS | CH-XS24V5A-R |  | | 24 | 5 | 538 | ✓ | 135*90*50 | 0.8 |
| XS | CH-XS24V10A-R |  | | 24 | 10 | 492 | ✓ | 135*90*50 | 1 |
| XS | CH-XS36V6A-R |  | | 36 | 6 | 655 | ✓ | 135*90*50 | 1 |
| XS | CH-XS48V5A-R |  | | 48 | 5 | 655 | ✓ | 135*90*50 | 1 |
| XS | CH-XS60V4A-R |  | | 60 | 4 | 983 | ✓ | 135*90*50 | 1 |
| XS | CH-XS72V3.4A-R |  | | 72 | 3.4 | 1311 | ✓ | 135*90*50 | 1 |
| XS | CH-XS84V2.5A-R |  | | 84 | 2.5 | 1311 | ✓ | 135*90*50 | 1 |
| XS | CH-XS96V2.5A-R |  | | 96 | 2.5 | 1311 | ✓ | 135*90*50 | 1 |
| S | CH-S12V20A-R |  | | 12 | 20 | 1966 | ✓ | 173*90*51 | 1.1 |
| S | CH-S12V25A-R |  | | 12 | 25 | 2580 | ✓ | 173*90*63 | 1.4 |
| S | CH-S24V15A-R |  | | 24 | 15 | 2580 | ✓ | 173*90*51 | 1.1 |
| S | CH-S48V10A-R |  | | 48 | 10 | 2540 | ✓ | 173*90*63 | 1.4 |
| M | CH-M12V40A |  | | 12 | 40 | 2650 | X | 220*120*70 | 2.1 |
| M | CH-M48V20A |  | | 96 | 20 | 2500 | X | 220*120*70 | 2.1 |
| L | CH-L12V50A |  | | 12 | 50 | 2500 | X | 260*158*92 | 3.9 |
| Ref | Fiche technique | Tension | Ampérage | Puissance | Redémarrage auto | Dimensions (L*W*H) | Poids | ||
|---|---|---|---|---|---|---|---|---|---|
| V | A | W | ✓ / X | mm | kg | ||||
| XS | CH-XS12V5A-R | | | 12 | 5 | 96 | ✓ | 135*90*50 | 0.8 |
| XS | CH-XS12V8A-R | | | 12 | 8 | 154 | ✓ | 130*86*46 | 0.8 |
| XS | CH-XS12V15A-R | | | 12 | 15 | 328 | ✓ | 135*90*50 | 1 |
| XS | CH-XS24V5A-R | | | 24 | 5 | 538 | ✓ | 135*90*50 | 0.8 |
| XS | CH-XS24V10A-R | | | 24 | 10 | 492 | ✓ | 135*90*50 | 1 |
| XS | CH-XS36V6A-R | | | 36 | 6 | 655 | ✓ | 135*90*50 | 1 |
| XS | CH-XS48V5A-R | | | 48 | 5 | 655 | ✓ | 135*90*50 | 1 |
| XS | CH-XS60V4A-R | | | 60 | 4 | 983 | ✓ | 135*90*50 | 1 |
| XS | CH-XS72V3.4A-R | | | 72 | 3.4 | 1311 | ✓ | 135*90*50 | 1 |
| XS | CH-XS84V2.5A-R | | | 84 | 2.5 | 1311 | ✓ | 135*90*50 | 1 |
| XS | CH-XS96V2.5A-R | | | 96 | 2.5 | 1311 | ✓ | 135*90*50 | 1 |
| S | CH-S12V20A-R | | | 12 | 20 | 1966 | ✓ | 173*90*51 | 1.1 |
| S | CH-S12V25A-R | | | 12 | 25 | 2580 | ✓ | 173*90*63 | 1.4 |
| S | CH-S24V15A-R | | | 24 | 15 | 2580 | ✓ | 173*90*51 | 1.1 |
| S | CH-S48V10A-R | | | 48 | 10 | 2540 | ✓ | 173*90*63 | 1.4 |
| M | CH-M12V40A | | | 12 | 40 | 2650 | X | 220*120*70 | 2.1 |
| M | CH-M48V20A | | | 96 | 20 | 2500 | X | 220*120*70 | 2.1 |
| L | CH-L12V50A | | | 12 | 50 | 2500 | X | 260*158*92 | 3.9 |
